In order to realize maximum performance from an A/D converter chip, many subtleties must be addressed in the external environment in order to make sure that the performance is not degraded. This paper briefly describes the architecture of an example A/D converter, discusses some trade-offs in the external circuit design, and concludes with some measurement issues and results. The techniques discussed also form a basis for users' own designs, allowing predictable realization of maximum performance.

Authors: Harris, Steven; Green, Steven; Leung, Ka
Affiliation: Crystal Semiconductor Corporation, Austin, TX
AES Convention: 103 (September 1997) Paper Number: 4530
Publication Date: September 1, 1997 Import into BibTeX
Subject: Signal Processing and Conversion
Permalink: https://www.aes.org/e-lib/browse.cfm?elib=7249
