The side-fringing response of magnetic heads is analyzed using results of recent calculations of three-dimensional side-fringing fields. It is shown that the two-dimensional distance-loss formula, when used for the calculation of the side-fringing response, exaggerates the loss figures up to 30% (2.4 dB). Normalized graphs are presented showing the corrections to be applied to the response without fringing in order to get the response with fringing.

Author: van Herk, A.
Affiliation: Philips Research Laboratories, Eindhoven, The Netherlands
JAES Volume 26 Issue 4 pp. 209-211; April 1978
Publication Date: April 1, 1978 Import into BibTeX
Permalink: https://www.aes.org/e-lib/browse.cfm?elib=3283

Click to purchase paper as a non-member or login as an AES member. If your company or school subscribes to the E-Library then switch to the institutional version. If you are not an AES member and would like to subscribe to the E-Library then Join the AES!

This paper costs $33 for non-members and is free for AES members and E-Library subscribers.

Learn more about the AES E-Library

E-Library Location: (CD aes4)   /jrnl7888/1978/7566.pdf
