A novel high-efficiency power amplifier topology for audio reproduction is presented. The topology breaks previous performance barriers in switching technology by combining an effective error-correction method, Multivariable Enhanced Cascade Control (MECC), with a new integrated modulator topology, Controlled Oscillation Modulation (COM). This topological combination proved to be very elegant. Extensive measurements are given on 250-W, 500-W, and 1000-W case implementations of the MECC/COM topology, showing, e.g., 0.0005% (-106-dB) true THD combined with state-of-the-art power and volume efficiency.:

Authors: Frederiksen, Thomas; Bengtsson, Henrik; Nielsen, Karsten
Affiliation: Bang & Olufsen PowerHouse a/s, Struer, Denmark
AES Convention: 109 (September 2000) Paper Number: 5197
Publication Date: September 1, 2000 Import into BibTeX
Subject: Analog Signal Processing
Permalink: https://www.aes.org/e-lib/browse.cfm?elib=9141

Click to purchase paper as a non-member or login as an AES member. If your company or school subscribes to the E-Library then switch to the institutional version. If you are not an AES member and would like to subscribe to the E-Library then Join the AES!

This paper costs $33 for non-members and is free for AES members and E-Library subscribers.

Learn more about the AES E-Library

E-Library Location: (CD aes15)   /pp9900/pp0009/109203.pdf
